آگهی مناقصه با عنوان Provision and Installation of Prefabricated Caravans و با کد هزاره 5737133 در تاریخ يكشنبه، 10 مهر 1401 در سایت ارتباط گستران هزاره ثبت شده است. این آگهی مربوط به کشور سوریه و در دسته بندی خانه های پیش ساخته (کانکس)، سایر مناقصه های ساختمان انتشار یافته است
خواهشمند است جهت کسب اطلاعات دقیق و شرکت در مناقصه، حتما به تصویر آگهی درج شده توسط
مناقصه گزار
مراجعه نمایید
کد هزاره:
5737133
شرح آگهی:
Provision and Installation of Prefabricated Caravans in Al Hol camp ‐ NES
1.Prefabricated Caravan for staff 400x300 Cm H=240 Cm internal,
Supplying the materials and installing prefabricated caravan (4x3 m)
according to the attached design drawings. The base consists of a double steel structure frame made by C‐section members 120x50x6 mm. within the frame a mesh of Rectangular iron tube members 80x40x2 mm. is spaced at 50 cm C/C. The poles at each corner shall be angle line members 100x100x3mm. The slab made by rectangular Iron tubes 80x40x2 mm for both the frame and the mesh. spaced at 90 Cm C/C in both directions. Using sandwich panel walls with a thickness of 5 Cm, for the side walls and the slab of the caravan. False ceiling shall be built by using PVC panels 60x60 Cm. The Floors shall be 18 mm plywood covered by 3mm vinyl sheeting. 1X PVC plastic Door (200x100 cm) and 2X PVC plastic windows (100x100 Cm). in addition to iron caps surrounding the inside‐face of the door and windows manufactured using rectangular iron tubes 40x60x2 mm. The price includes painting works with three layers of paint, one layer of anti‐rust paint and two layers of oil paint. The price also includes the implementation of a metal protection mesh (grill) for the doors and windows consisting of a perimeter metal frame 30x20x2 mm with internal metal frames 20x20x2 mm at every 15 cm, for vertical and 3 horizontal iron box for each door or window. The Work shall be done according to drawings and the...
1.Prefabricated Caravan for staff 400x300 Cm H=240 Cm internal,
Supplying the materials and installing prefabricated caravan (4x3 m)
according to the attached design drawings. The base consists of a double steel structure frame made by C‐section members 120x50x6 mm. within the frame a mesh of Rectangular iron tube members 80x40x2 mm. is spaced at 50 cm C/C. The poles at each corner shall be angle line members 100x100x3mm. The slab made by rectangular Iron tubes 80x40x2 mm for both the frame and the mesh. spaced at 90 Cm C/C in both directions. Using sandwich panel walls with a thickness of 5 Cm, for the side walls and the slab of the caravan. False ceiling shall be built by using PVC panels 60x60 Cm. The Floors shall be 18 mm plywood covered by 3mm vinyl sheeting. 1X PVC plastic Door (200x100 cm) and 2X PVC plastic windows (100x100 Cm). in addition to iron caps surrounding the inside‐face of the door and windows manufactured using rectangular iron tubes 40x60x2 mm. The price includes painting works with three layers of paint, one layer of anti‐rust paint and two layers of oil paint. The price also includes the implementation of a metal protection mesh (grill) for the doors and windows consisting of a perimeter metal frame 30x20x2 mm with internal metal frames 20x20x2 mm at every 15 cm, for vertical and 3 horizontal iron box for each door or window. The Work shall be done according to drawings and the...
شرایط آگهی:
Closing Date:09/10/2022
برگزار کننده:
Blumont - Iraq
منطقه:
کشور سوریه
تاريخ انتشار:
1401/07/10
مهلت دريافت:
اعلام نشده
مهلت ارسال:
1401/07/17
تاريخ بازگشايی:
اعلام نشده
نوبت اعلام:
اعلام نشده
شماره آگهی:
SYRIA‐TA‐2022
منبع:
NGO Coordination committee for Iraq
تلفن:
اعلام نشده
فکس:
اعلام نشده
ایمیل:
اعلام نشده
وب سایت:
اعلام نشده
آدرس:
refer to tender document
اسناد آگهی:
سفارش اسناد
تصویر آگهی:
